Timer and activating box TA2 for 2 service & multi coin validator
Coin or token operated Acceptor for 2 pay timed services. Useful for: lights for playing fields, internet terminals, electronic games, washing machines, vacuums, solariums, air conditioners for seaside establishments, treadmills, etc. For showers or water service please see models TA10w and TA20w .
Applications for timed electronic coin Acceptors:
control of washing machines and dryers in Laundromats - management of washing cycles
lighting systems for playing/sport fields - management of lights
tanning bed lights or other mechanisms in beauty salons and solariums
Billiards lights/lamps
Internet Point stations - access to internet
activation systems for payment services - coin, token, or prepaid card services
vacuum and car wash systems
air conditioners for seaside establishments
game rooms - videogames - electronic games
gym equipment, treadmills, hairdryers
etc.
The introduction of coins/tokens closes the relay contacts to which the electrical load to be controlled must be connected.
Relay 10A. Allows for a maximum electrical load of 2300VA with 230V, or 1150VA with 115V. The contact can also be used for closing low voltages or command signals.
The time of service (closing of the relay) can be easily adjusted from 1 second to 24 hours for each coin/token inserted.
Optional accumulation of time feature. If this feature is activated, inserting more coins will increase the time of service (maximum 48 hours). If deactivated, coins inserted during service will be rejected and returned, thereby preventing disputes from customers.
It is possible to delay the start of service once coins have been inserted. This is useful when the customer needs more time before accessing the service.
A light display (OLED) helps to illuminate the cost of the service when in use, the remaining time, and facilitates configuration.
Multilingual: There are 5 languages to choose from (Italian, English, French, Spanish, German), facilitating easier comprehension of product instructions and use.
Start/Pause buttons can be connected externally, enabling the customer to activate or stop the service. The maximum time for a pause can be adjusted.
The automatic pause function temporarily interrupts the supply of water. It may be used to inform customers of the end of service.
The function end of service notice utilizes a special output to warn customers of the end of service without interrupting the service. In this mode every TA service occupies 2 outputs (relay), reducing the number of available services by half (except on the TA10 which already has 2 outlets).
The counting time is memorized in case power supply is interrupted and will automatically resume when power is restored. This prevents the time from being reset when brief interruptions occur and from any ensuing complaints.
Coins inserted when the TA is not in service will be rejected and returned, thereby preventing disputes from customers.
Electronic multi-coin Acceptor. Useful for allowing the TA to accept up to 6 different types of coins. The operator can programme the coins by inserting each type of coin repeatedly. The programmed time on the TA relates to the coin of least value; the other 5 coins must have a multiple value of this. It is also possible to allow the Acceptor to accept two different coins (or one coin and one token) of the same value.
For more information see OPTIONS.
Sturdy metal container, with high resistant coating for outdoors (cataphoresis and powder). International protection rating IP30. As an option (see OPTIONS), the TA can be furnished with protection from rain and water (International protection rating IP34) and/or with stainless steel container.
Large coin drawer that can hold circa 400-500 coins/tokens.
Size and weight: height 26 cm, width 22.5 cm, length 14 cm, weight 3.1 kg. The small dimensions of the article reduce bulkiness and make it more aesthetically pleasing.
Power supply: 100-240V, 0.35A, 50-60 Hz.
Warranty: 2 years
Options:
As an option the TA can also come with an electronic comparable coin Acceptor which is easily programmable to accept any type of coin or token. Simply place a sample coin or token in the appropriate slot of the Acceptor and the coin/token will serve as a reference for all other coins/tokens inserted. It is easy then to change the type of coin that the TA will accept.
Stainless steel container. Useful in case the TA is installed in environments with harsh conditions such as humid, saline or hostile surroundings, seaside resorts or in the presence of possible splashing water or condensation.
